Double Eccentric Design

Double eccentric disc geometry provides 360° continuous sealing between body seat and disc seat — the disc leaves the seat immediately after opening, ensuring long service life.

Bi-Directional Tight Shutoff

Bi-directional tight shutoff across all sizes and AWWA pressure classes 25B, 75B and 150B for reliable isolation in both flow directions.

Large Bore Range

Covers DN350–DN2600 (14"–104") across AWWA C504 and C516 — one of the largest size ranges available in a double flanged butterfly valve.

Hard Rubber Lining Option

Body and disc can be hard rubber lined on request to prevent corrosion from seawater. Rubber liner tested to 20,000V DC holiday test — no pin holes guaranteed.

In-Line Seat Replacement

For sizes DN750 (30") and above the seat ring can be replaced without removing the valve from the pipeline — significantly reducing maintenance downtime.

AWWA C504 & C516 Compliant

Fully designed and manufactured to AWWA C504 for 14"–72" and AWWA C516 short type for 78"–104", with face to face dimensions per AWWA standards.

Wide Seat Material Options

NBR (-10°C to +90°C), EPDM (-20°C to +120°C), Neoprene (0°C to +80°C) and FKM (-18°C to +204°C) seat options for all media types.

ISO 5211 Actuator Mounting

ISO 5211 mounting flange for direct actuator mounting — compatible with gear box, pneumatic, electric and hydraulic actuator configurations.

Special Offers Available

Floor stands, lantern glands, mechanical shaft locking devices, extension stems, extension gearbox shafts and hard rubber lining available on request.

Multiple Body Materials

Cast iron, ductile iron and stainless steel body options across the full size range to suit fresh water, seawater and process media requirements.

Monel Shaft Option

Monel K500 and Monel 400 shaft options available for corrosive seawater and chemical service applications requiring superior corrosion resistance.

Water & Power Applications

Primary applications in water works, water treatment, seawater systems, exhaust and power plant condensate service — the benchmark AWWA butterfly valve.
