WKM 370D Flanged Ball Valve by Cameron — engineered for reliable, leak-tight isolation and flow control in demanding industrial process conditions.
2"–16" | 50–400 mm
ASME CL 150–2500
Flanged
High-Integrity Isolation
API Rated
Oil & Gas, Petrochemical, Refining
Engineered for demanding industrial environments
Reliable leak-tight isolation across full pressure range
Sourced from trusted global manufacturers
Available on request — lead time confirmed on quotation
RPX Actuated Ball Valve
Size Range: NPS 1/2–8 | DN 15–200
Deltaflux Trunnion Mounted Control Ball Valve
Size Range: 2"–48" | NPS 50–1200
2-Piece Floating Ball Valve
Size Range: 1/2"–12" (DN15–DN300)The Cameron WKM 370D is a flanged ball valve intended for high-integrity isolation in oil and gas, petrochemical and refining service. Valvenok lists it in sizes from 2 to 16 inches (50 to 400 mm) with flanged end connections and pressure classes from ASME Class 150 up to Class 2500, so a single valve family can cover everything from low-pressure utility headers to high-pressure production and transmission lines.
Like any ball valve, the 370D isolates flow by turning a ported ball through a quarter turn. Larger, higher-class ball valves are often trunnion-mounted, with the ball supported on fixed shafts so the seats rather than the ball move to seal; this reduces operating torque compared with a floating-ball design. Check the datasheet for the exact construction, trim and seat materials of the configuration you need, as these vary by size and class.
Selecting the right variant starts with the pipeline design pressure and temperature, which set the ASME class, followed by the bore size, flange facing and the operator. Larger and higher-class valves are usually fitted with a gearbox or actuator rather than a lever. Where project documentation calls for specific API or customer specifications, state them on the enquiry so the offer can be checked against them.
