Compact double-acting pneumatic linear actuators designed for fine automation and precise linear motion in space-constrained environments. Modular construction, IP66 protection, and full support for positioners, solenoids and limit switches.
2.1 – 6.2 bar
IP66
-10°C to +60°C
Up to 8 bar
Double Acting — controlled motion in both directions
2.1 – 6.2 bar (30 – 90 PSIG)
Up to 8 bar
-10°C to +60°C
-20°C to +80°C
IP66
Compact modular — optimized for tight spaces
High-quality durable materials for long service life
Optional handwheel or hydraulic override
Positioners, limit switches, solenoid valves
Custom mounting dimensions available on request
Certified — Industrial Grade
Compact Design
Optimized for tight spaces and miniature automation equipment.
IP66 Protection
Fully sealed body prevents dust and water ingress in challenging environments.
Double Acting Mechanism
Provides controlled motion in both stroke directions for precise functionality.
High-Quality Build
Durable construction ensures long service life and consistent performance.
Modular Design
Supports easy maintenance, installation, and customization — reducing downtime.
Wide Pressure Range
Operates between 30–90 PSIG to meet varied automation requirements.
Temperature Flexibility
Optional high and low temperature trims for harsh or specialized environments.
Multiple Control Options
Supports solenoids, limit switches, positioners, and micro-automation accessories.
Manual Overrides
Optional handwheel or hydraulic override available for emergency operation.
IP66
Ingress Protection
30–90 PSIG
Operating Pressure
Up to 8 bar
High-Pressure Option
Modular
Design Architecture
Positioner Ready
Control Options
